Frequency Range (-10 dB) 41 Hz - 20 kHz (Preset: Flat) Horizontal Coverage (-6 dB) 90° nominal (400 Hz – 16 kHz) Vertical Coverage Varies with array size and configuration. System Power Ratings (AES) LF: 1000W Continuous (IEC/100 hour)
MF: 400W Continuous (IEC /100 hour)
HF: 160W Continuous (IEC /100 hour)
Maximum SPL 146dB (Preset: Flat)
Low Frequency Driver 2 x JBL 2265H, 15in diameter, dual 3in diameter voice coil, Neodymium Differential Drive
Nominal Impedance 4 ohms
Mid-Frequency Driver 2 x JBL 2169H, 8in diameter, dual 3in diameter voice coil, Neodymium Differential Drive
Nominal Impedance 4 ohms
High-Frequency Driver 3 x JBL 2432H, 1.5in exit compression driver, 3in diameter voice coil, Neodymium Magnet Nominal Impedance 16 ohms
