Frequency Range (-10 dB) 39 Hz - 19 kHz (Preset: Flat)
Horizontal Coverage (-6 dB) 30° nominal (900 Hz – 16 kHz) Vertical Coverage Varies with array size and configuration. System Power Ratings (AES) LF: 1000W Continuous (IEC /100 hour)
MF: 400W Continuous (IEC /100 hour)
HF: 160W Continuous (IEC /100 hour)
Maximum SPL 151.1dB (Preset: Flat)
Low Frequency Driver 2 x JBL 2265H, 15in diameter, dual 3in diameter voice coil, Neodymium Differential Drive
Nominal Impedance 4 ohms
Mid-Frequency Driver 4 x JBL 2169H, 8in diameter, dual 3in diameter voice coil, Neodymium Differential Drive
Nominal Impedance 8 ohms
