Compatibility CSS-BB4 and CSS-BB8 backcans
Dimensions 600 x 36 x 8 mm
(23.6 x 1.4 x 0.3 in)
Bolt Mount Circle N/A
Air Space N/A
Material Punched/formed steel, zinc-plated
Conduit Knockouts N/A
Attachment Points 2 points screw onto backcan, each rail.
Safety Agency Suitable for use in air handling spaces per UL1480, UL2043, NFPA 90 & NFPA 70, when installed with corresponding UL Listed loudspeaker, above. S7232/UL Listed, Signaling Speaker. CUL Listed. In accordance with IEC60849/EN60849.
Net Weight (ea) 0.18 kg (0.4 lb)
Shipping Weight (ea) 0.21 kg (0.5 lb)
Included Accessories M4 x 8 mm machine screws for attaching rails
