Frequency Response (at 1 watt from line out): 50 Hz to 20 kHz +/-1 dB, 19 Hz to 34 kHz - 3 dB
Signal to Noise Ratio (ref. to rated power, master volume at minimum): Mic: > 58 dB, Line: > 60 dB, Telephone: > 60dB, Inputs 2 or 3: > 78 dB
THD+Noise < 0.5% at rated power at 1 kHz, < 0.1% at 5W at 1 kHz
Input Sensitivity (for full output at miximum gain): Input 1: Mic 3mV, Line 800 mV, Input 2: 400mV, Input 3: 400mV
Input Impedance (nominal) Mic: 2.2 kilohms, Line: 10 kilohms, RCA: 10 kilohms
Crosstalk -82 dB at 1 kHz (Ch. 1 line inpute 0.8V, Ch. 1 volume at minimum, other channel volumes at maximum)
Line Output Level (nominal) 1V into 10 kilohms
Phantom Power 15 VDC
AC Line Voltages Available Universal Power Supply. Line voltage tolerance +15%, -20% Operating Temperature/Humidity 0 degrees C to 40 degrees C at 95% relative humidity (non-condensing)
Storage Temperature -20 degrees C to 85 degrees C
IEC Power Connector 15A
