Eight-Channel, 125W @ 4 Ohms Power Amplifier

Short description

Eight-Channel, 125W @ 4 Ohms Power Amplifier

Name: Eight-Channel, 125W @ 4 Ohms Power Amplifier
SKU: CT8150A

Brand: Crown

Model: CT8150A

UPC: 871015004839

Please log in to see your price

About This Product

Description:

Powering this remarkable amplifier is the pioneering technology of DriveCore™, which integrates the amplifier drive stage into the power output stage fusing everything into a chip the size of a dime. DriveCore's front-end drive circuits leverage the inherent efficiency of Class D output stages while also maintaining superb sonic characteristics. The end result is an audio amplifier circuit that exhibits the exemplary audio quality of a highly evolved Class AB design.

Channels 8

Sensitivity 1.4 V

Rated Power Output (all channels driven) 125W per CH @ 4 ohms, 125W per CH @ 8 ohms

Signal to Noise Ratio (below rated power 20 Hz to 20 kHz, A-Weighted) 110 dB

THD (full rated power, 20 Hz - 20 kHz) < 0.05%

Intermodulation Distortion (from 0 dB down to -30 dB) < 0.05%

Frequency Response (at 1W, 4/8 ohms) +/- 0.5 dB

Crosstalk (below rated power) 20 Hz to 1 kHz > 70 dB

Common Mode Rejection (20 Hz to 1 kHz) > 55 dB, typically > 70 dB

Voltage Gain 27 dB

DC Offset +/- 20mV

Idle Power Consumption (Standard Mode) 25.5W

Dimensions 1.75" x 19" x 15.19"

Weight 10lbs/4.54kg

Shipping Weight 15 lbs/6.8 kg

IEC Power Connector 15A
