Large vent area for high output.
Parallel/Discrete Switchable.
See Array Guide on applications such as performing arts facilities, theatrical sound design, auditoriums, houses of worship, live clubs, dance-clubs/discotheques, sports facilities and themed entertainment venues.
Frequency Range 30 Hz – 1 kHz (-10 dB)
Frequency Response 40 Hz – 1 kHz ( ± 3 dB)
Input Modes Drivers Parallel / Drivers Discrete
Transducer Power Rating (AES) 1000 W (4000 W peak), 2 hrs
Long-Term System Power Rating (IEC) 600 W (2400 W peak), 100 hrs
Maximum SPL 30 Hz – 100 Hz: 133 dB-SPL cont avg (139 dB peak) 100 Hz – 500 Hz: 133 dB-SPL cont avg (139 dB peak)
System Sensitivity 30 Hz – 100 Hz: 103 dB 100 Hz – 500 Hz: 103 dB
Nominal Impedance 4 ohms in parallel-drive mode 2 x 8 ohms in discrete-drive mode
