Frequency Range 22 Hz – 300 Hz (-10 dB)
Frequency Response 25 Hz – 300 Hz ( ± 3 dB)
Input Modes Drivers Parallel / Drivers Discrete
Transducer Power Rating (AES) 2400 W (9600 W peak), 2 hrs
Long-Term System Power Rating (IEC) 1600 W (6400 W peak), 100 hrs
Maximum SPL 30 Hz – 100 Hz: 132 dB-SPL cont avg (138 dB peak) 100 Hz – 300 Hz: 136 dB-SPL cont avg (142 peak)
System Sensitivity (dB-SPL, 1W @ 1m) 25 Hz - 80 Hz 98 dB 80 Hz - 200 Hz: 102 dB
Nominal Impedance 4 ohms in parallel-drive mode 2 x 8 ohms in discrete-drive mode
