Frequency Range 80 Hz - 20 kHz
Power Capacity 150 W Continuous Program Power; 75 W Continuous Pink Noise
Transformer Taps 70V: 60W, 30W, 15W & 7.5W
100V: 60W, 30W, & 15W
Nominal Coverage Angle 110° conical coverage
Directivity Index (DI) 4.6 averaged 500 Hz to 4 kHz
Rated Maximum SPL 107 dB @ 1 m (3.3 ft)
Low-Frequency 165 mm (6.5 in) Polypropylene-coated, 1" coil on aluminum former
High-Frequency 19 mm (¾ in) Titanium coated polyester Termination Removable locking connector with screw-down terminals. 2 input terminals and 2 loop-thru output terminals. Max. wire 12 AWG (2.5 mm2)
Outside Dimensions (H x Dia) 210 x 252 mm (8.3 x 9.9 in)
190 mm (7.5 in) front of ceiling tile to back of backcan
Net Weight (ea) 4.2 kg (10 lb) Shipping Weight (pair) 9.7 kg (21 lb)
