Freq. Range (-10 dB) 80 Hz - 20 kHz
Power Capacity 80 Watts Continuous Program Power; 40 Watts Continuous Pink Noise
Transformer Taps 70 V: 30W, 15W, 7.5W & 3.7W taps
100 V: 30W, 15W, & 7.5W taps
Nominal Sensitivity 86 dB SPL @ 1 m (3.3 ft)
Nominal Coverage Angle 130° conical coverage
Directivity Factor (Q) 2.4 averaged 500 Hz to 4 kHz
Directivity Index (DI) 3.8 averaged 500 Hz to 4 kHz
Transformer Insertion Loss Max 0.8 dB
Low-Frequency Transducers 100 mm (4.0 in) Polypropylene-coated, 1" coil on aluminum former
High-Frequency Transducers 19 mm (0.75 in) Titanium coated polyester
Enclosure Backcan: Formed steel
Baffle/Rim: Medium impact polystyrene, fire rated UL94V-0
Termination Removable locking connector with screw-down terminals.
2 input terminals and 2 loop-thru output terminals.
Max. wire size 12 AWG (2.5 mm)
Outside Dimensions (H x Dia) 200 x 195 mm (7.9 x 7.7 in)184 mm (7.2 in) front of ceiling tile to back of backcan
