The Soundweb London Analog Output Card is designed to populate any of the four card slots on Soundweb London BLU-800, BLU-805, BLU-806, BLU-320, BLU-325, BLU-326, BLU-160, BLU-120, BLU-80, BLU-32 and BLU-16 devices. This analog card enables Soundweb London devices to send line level signals.
The Analog Output Card has two Combicon connectors which are used as follows:
Connector 1
Balanced / Unbalanced Audio, Channel 1 - Mic/Line
Balanced / Unbalanced Audio, Channel 2 - Mic/Line
Connector 2
Balanced / Unbalanced Audio, Channel 3 - Mic/Line
Balanced / Unbalanced Audio, Channel 4 - Mic/Line |
